CNC & VMC at Machining Shop Floor

CNC & VMC at Machining Shop Floor
CNC & VMC at Machining Shop Floor

Injection Molding Shop Floor

Injection Molding Shop Floor
  • Shop floor area 7000 sq. ft.
  • Stores space 4000 sq. ft.
  • FG space 2000 sq. ft.
  • Epoxy coated floor for dust free environment.
  • Crane capacity 7.5 Tons
  • Inspection room
  • Mould storage area

Capabilities in Plastic Injection Moulding

Capabilities in Plastic Injection Moulding
  • Ferromatik-Hydron Servo 200Ton
  • Mould Opening: Min. 200-Max.620mm Max.
  • Tie Bar Distance:510X510mm Max.
  • Shot Weight:275Gms
Capabilities in Plastic Injection Moulding
  • Ferromatik-Hydron Servo 300 Ton
  • Mould Opening:Min. 250-Max.830mm Max.
  • Tie Bar Distance:620X620mm Max.
  • Shot Weight:450Gms
Capabilities in Plastic Injection Moulding
  • 2R 60Ton-Vrtical Moulding Machine
  • Mould Opening:Min.200mm-Max.500mm
  • Max. Tie Bar Distance:410X410mm
  • Max. Shot Weight:60Gms

Capabilities at Dies and Mould Shop Floor

Well organised-Methodical-Conscientious-Efficient-Numerically Inclined-Confirming

Capabilities at Dies and Mould Shop Floor
HMT-Lathe Machine
Capabilities at Dies and Mould Shop Floor
Surface Grinding Machine
Capabilities at Dies and Mould Shop Floor
Radial Drilling Machine - ZJ
Capabilities at Dies and Mould Shop Floor
Radial Drilling Machine
Capabilities at Dies and Mould Shop Floor
M1Tr Milling Machine

Inspection Area

Inspection Area

Online Inspection Area for Moulding Products

Online Inspection Area for Moulding Products
  • Online inspection area beside every injection moulding m/c.
  • All required fixture and gauges available as per QAP and drawing.
  • Critical dimensions are checked properly.

Testing Facility

Provision for testing all kind of products up to 25 kg/cm2 Precise and calibrated gauges for gauging flow rate and pressure as per requirement.

Testing Facility
Testing Facility
Testing Facility

As per customer requirements we develop the testing fixtures and conduct the test for product validation and regular testing during production.
